MIL-PRF-63033C(TM)
Table I. Manual sizes (in inches).
Maximum Printing
Trim Size
Format
Style
Area
Pocket
4 x 5-1/2
Vertical
3-3/8 x 5-1/4
5-1/2 x 4
Horizontal
5-1/4 x 3-3/8
Logbook
6-1/2 x 9-1/2
Vertical
5-51/6 x 8-3/4
9-1/2 x 6-1/2
Horizontal
8-3/4 x 5-5/16
Standard
8-1/2 x 11
Vertical
7 x 10
11 x 8-1/2
Horizontal
10 x 7
Double
Horizontal
15-1/2 x 9
17 x 11
Standard
Only
3.1.6.1 Pocket TM. Pocket TM numbers shall appear on the front and back cover only. Page
numbers shall appear on lower, outer edges of each page.
3.1.6.2 Horizontal TM. Unless otherwise specified by the contracting activity (see 6.2), TMs
prepared in horizontal format shall be printed head to foot with holes punched at the bottom of
even numbered pages and at the top of odd numbered pages. Except for pocket TMs, the TM
number shall appear on the upper right corner of all pages. The upper pages shall have even
numbers, and the lower pages shall have odd numbers.
3.1.6.3 Font size. Except for pocket size TMs, font size shall be no smaller than 8 point.
3.1.6.4 Foldout/foldup pages. Foldout/foldup pages shall not be used.
3.1.7 Security classification markings. Security classification markings, if applicable, shall be
applied in accordance with MIL-STD-40051-2.
3.2 Content <demil> . The TM for demilitarization of surplus military items shall consist of the
following:
a. Front matter
b. General Information Work Package
c. Methods of Demilitarization Work Package
d. Detailed Instructions for Demilitarization Work Package
e. References Work Package
f. Rear Matter
3.2.1 Front matter <demil-frnt>. Unless otherwise specified by the contracting activity (see
6.2), the front matter shall consist of the following described information.
3.2.1.1 Front cover <frntcover>. Unless specified in the following, the front cover shall be
prepared in accordance with MIL-STD-40051-2. For format, see FIGURE 1.
3.2.1.1.1 Title <tmtitle>. The title shall be "Demilitarization Procedures for (insert name of item
to be demilitarized)."
3.2.1.1.2 Notices <notices>. The following notices shall appear as specified. Notices shall not
be boxed.
3.2.1.1.2.1 Supersedure notice (for revisions only) <super>. When a TM is revised, a
supersedure notice shall be included and an asterisk (*) shall prefix the supersedure notice and
the TM number.
3
