MIL-DTL-24784/20B (SH)
MASTER FBO BY
SYSTEM FUNCTION
U
U
U
N
N
N
I
I
I
T
T
T
UNIT FUNCTIONS
PRIMARY FBO
UNIT FUNCTIONS
SECONDARY FBO'S
UNIT FUNCTIONS
* AS REQUIRED
LOWER LEVEL FBO'S *
** REFERENCE TO UNIT FCD'S
OR DIRECTLY TO HARDWARE
**
REFERENCE DESIGNATOR
UNIT FCD'S
FIGURE 20-1. FBD/FCD structure and relationship.
(Example)
