MIL-DTL-24784 / 21B (SH)
UNACCEPTABLE
ACCEPTABLE
FIGURE 21-17. General flow. (Example)
COMPLETE
EXIT
START
ADJUST AND ALIGN
PER PARAGRAPH X.X.X
FIGURE 21-18. Terminal blocks
FIGURE 21-19. Annotation/comment block. (Example)
