MIL-PRF-63016 Manuals, Technical: Munitions Equipment \(See Notice 1 For Replacement Information\)This specification contains requirements for the preparation of operator and maintenance technical manuals for munitions equipment \(e.g., chemical, mechanical, electrical, electronic, pneumatic, hydraulic, or combination thereof\). Manuals prepared using this specification cover equipment including commercial items adapted for military use; specifically designed test, handling, measuring, and diagnostic equipment; and non-explosive equipment which is a separate component of a munitions system.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11

MIL-PRF-63016B (TM)

TABLE I. Manual sizes (in inches).

Style

Trim Size

Format

Maximum Printing

Area

Pocket

4 x 5-1/2

Vertical

3-3/8 x 5-1/4

5-1/2 x 4

Horizontal

5-1/4 x 3-3/8

Logbook

6-1/2 x 9-1/2

Vertical

5-5/16 x 8-3/4

9-1/2 x 6-1/2

Horizontal

8-3/4 x 5-5/16

Standard

8-1/2 x 11

Vertical

7 x 10

11 x 8-1/2

Horizontal

10 x 7

Double

17 x 11

Horizontal

15-1/2 x 9

standard

Only

3.1.10.1 Pocket TM. Pocket TM numbers shall appear on the front and back cover only. Page numbers

shall appear on lower, outer edges of each page.

3.1.10.2 Horizontal TM. Unless otherwise specified by the contracting activity (see 6.2), TMs prepared

in horizontal format shall be printed head to foot with holes punched at the bottom of even numbered pages

and at the top of odd numbered pages. Except for pocket TMs , the TM number shall appear on the upper

right corner of all pages. The upper pages shall have even numbers, and the lower pages shall have odd

numbers.

3.1.10.3 Font size. Except for pocket size TMs, font size shall be no smaller than 8 point.

3.1.10.4 Foldout/foldup pages. Foldout/foldup pages shall not be used.

3.1.11 Security classification markings. Security classification markings, if required, shall be applied in

accordance with MIL-STD-38784.

3.2 Type 10 - Operator's manual. Unless otherwise specified, the arrangement of the manual shall be

as follows:

Front Matter

Chapter 1

Introduction

Chapter 2

Operating Instructions

Chapter 3

Maintenance Instructions

Appendix A

References

Appendix B

Expendable and Durable Items List

Glossary

Index

3.2.1 Front matter. Front matter shall be prepared in accordance with MIL-STD-38784.

3.2.2 Chapter 1 - introduction. This chapter shall consist of the following sections:
