MIL-DTL-38807D
3.6.7.4.1 Indentation. The description for parts listed shall be indented to indicate relationship. The
indentation shall be indicated by leader points, each point shall signify each indentation. When the
description exceeds one line, the second (and succeeding lines) shall be indented two additional indentations
from the irst line.
Description
1234567
END ITEM, COMPONENT, MAJOR ASSEMBLY
. DETAIL PARTS FOR END ITEM, COMPONENT, MAJOR ASSEMBLY
. ASSEMBLY
. Attaching parts for assembly (AP)
. . Detail parts for assembly
. . Subassemblies
. . Attaching parts for subassemblies (AP)
. . . Detail parts for subassemblies
. . . Sub-subassemblies
. . . Attaching parts for sub-subassemblies (AP)
. . . . Detail parts for sub-subassemblies
3.6.7.5 Units per assembly column. The column shall show the following:
a. Quantity required for each detail part in an assembly.
b. Quantity required for each assembly in the next higher assembly.
c. Quantity required for each attaching part to attach one unit or one assembly.
d. The abbreviation "AR" for oversize and undersize parts and "as required" for parts when
quantities are indeinite.
e. The abbreviation "REF" where items are listed for reference purposes. Such items shall show a
quantity where the item is listed assembled, or listed in detail, and show "REF" in other listings.
f. The quantity shall be listed opposite the irst line of the description when the description
requires more than one line.
3.6.7.6 Useable on code column. This column shall contain codes to indicate the conigurations (type, model,
series, blocks, etc.) of the end items to which listed assemblies and parts apply. When a part applies to all
conigurations, no code is required in this column; likewise, when the manual covers only one coniguration,
no coding system is required. The coding system shall consist of letters of the alphabet beginning with single
letters, A through Z, and when necessary, continue with double letters, AA through AZ, BA, through BZ, etc.
3.6.7.6.1 Useable on code. The meaning of Useable on Codes, if used, shall appear at the end of each
MPL (for each igure) in the description column (see igure7). Example:
CODE
USeABLE ON
A
Aircraft Number/Serial Number through Aircraft Number/Serial Number
B
Aircraft Number/Serial Number through Aircraft Number/Serial Number before TCTO
XX-XX-XXX
C
Aircraft Number/Serial Number through Aircraft Number/Serial Number after TCTO
XX-XX-XXX
The MPL shall not list Time Compliance Technical Orders (TCTOs) that have been completed.
3.6.7.7 SMR code column. This column shall contain the Joint Military Services Uniform SMR codes
assigned by the government and furnished by the acquiring activity. The deinitions of these codes are
available in TO-00-25-195. When codes are not available for publication in the initial issue, scheduled
10
