MIL-DTL-83495C (USAF)
3.3.5.3.2.1 Special tools and test equipment list. When speciied, illustrations of peculiar equipment shall
follow the table listing special tools/support equipment (see 6.2l.). Electronic media requirements: If the
table spans more than a screen it shall be formatted as a scrolling table. Print media requirements:
The table shall be formatted as follows:
SPECIAL TOOLS AND TEST EQUIPMENT
Part Number/
Figure and
Item
Nomenclature
Type Designation
CAGE Code
Index Number
a. Item. Consecutive numbers shall be used for individual items.
b. Nomenclature. Nomenclature shall be in accordance with the requirements of MILSTD- 38784.
c. Part number/Type Designation. Special tools and test equipment shall be listed in alphanumeric
sequence by part number/type designation. If alternate or suitable substitutes may not be
used, footnotes to the table shall so state.
d. CAGE Code. The Commercial and Government Entity (CAGE) Code or manufacturer s name
and address if no CAGE Code is assigned.
e. Figure and index number. The igure and index number shall be shown.
3.3.5.3.2.2 List of consumable materials. Consumable materials and expendable items shall be listed. All
chemicals shall be grouped separately at the beginning of the list. Electronic media requirements: if the
table spans more than a screen it shall be formatted as a scrolling table. Print media requirements: The list
shall be in tabular format, in alphabetical order by nomenclature, as follows.
LIST OF CONSUMABLE MATERIALS
Item
Use
Nomenclature
Speciication/PN
CAGE Code
Reference
a. Item. Consecutive numbers shall be used for individual items.
b. Nomenclature. Nomenclature shall be in accordance with the engineering drawing title block
and MIL-STD-38784.
c. Speciication / PN. The military, Government, commercial speciication number or part number
shall be shown.
d. CAGE code. The CAGE Code or manufacturer s name and address shall be used if a CAGE
Code has not been assigned.
e. Use. The purpose and primary use of each item shall be included.
f. Reference. Reference where each item will be used.
3.3.5.3.3 Chapter 3, system peculiar maintenance. This chapter shall contain system peculiar maintenance
that does not lend itself to Job Guide format, e.g., structural crack limitations.
3.4 Job guide (JG) manual. JG manuals shall provide complete detailed procedures for on equipment
maintenance. These procedures shall be organized into a series of publications with a separate manual, or
manuals, for each major system. Separate manuals may be prepared for a subsystem(s) when necessary due
to equipment complexity. SSSN breakouts shall be in accordance with MIL-STD-1808.
3.4.1 Scope. The JG manual shall provide detailed start-to-inish, step-by-step, maintenance instructions.
Each procedure shall be arranged in logical sequence. Instructions shall be fully illustrated to support the text.
Instructions shall cover removal, installation, alignment (electrical and mechanical), adjustment, calibration,
operational checkout, and other maintenance procedures as applicable, including operation of special equipment.
3.4.2 General requirements.
