MIL-DTL-87929D

APPENDIX I

1. WP 010 00 Foreword/System Description (see I.3.5.1).

2. WP 020 00 Safety Summary and Accident Prevention (see I.3.5.2).

3. WP 030 00 Master Lists of Special Tools, Equipment, and Consumables (see I.3.5.3).

4. WP 040 00 Storage and Handling Requirements (see I.3.5.4).

5. WP 050 00 Inspection Requirements and Procedures (see I.3.5.5).

6. WP 060 00 Unpacking and Packaging (see I.3.5.6).

7. WP 070 00 Maintenance (see I.3.5.7).

8. WP 998 00 Illustrated Parts Breakdown (see I.3.5.8).

b. When used, the following WPs shall be numbered and titled as follows:

1. WP 080 00 Testing/Reprogramming (see I.3.5.9).

2. WP 090 00 Contingency Procedures (see I.3.5.10).

3. WP 100 00 Depot Related Data and Special Instructions (see I.3.5.11).

4. WP 110 00 - WP 997 00 Any other WP as speciied by acquiring activity (see I.3.5.12, I.6.1).

I.3.5.1 Foreword/System Description WP (WP 010 00). The Foreword/System Description WP will always

be the irst WP and the requirements of MIL-DTL-87929, 3.4.3.2, apply, with the following exceptions:

a. The requirements of MIL-DTL-87929, 3.4.3.2 (a.), (b.), and (c.) do not apply.

b. The requirements of MIL-DTL-87929, 3.4.3.2 (d.), except for the hazardous materials icon

requirements of MIL-STD-38784 which shall be included in the Safety Summary and Accident

Prevention WP. Only non-USAF standard abbreviations/acronyms need be explained.

c. In addition, the following shall be included:

I.3.5.1.1 Description of item. A physical and functional description of the item and each component

shall be included. When applicable, a detailed theory of operation shall also be included. Appropriate

illustrations shall be included.

I.3.5.1.2 Table of leading characteristics. Table of leading characteristics. A table of leading characteristics

shall be provided in landscape orientation. The table shall list the nomenclature, FSC/DODIC (Department of

Defense Identiication Code), Part No./Model No./CAGE, length, width, diameter, center of gravity, weight,

net explosive weight (NEW), and Dimensions Outer Pack for the item and each component, as applicable.

Table

Leading

Characteristics

Nomen-

Center

Dimensions (Inches)

Weight (Pounds)

FSC/

Part/

Dimen-

clature

DODIC

Model

sions

Gross

NEW

Length

Width

Height

Diam-

Gravity

No.

(Inches)

eter

CAGE

Outer

Code

Pack

I.3.5.1.3 Markings. The physical description illustration(s) shall be used to show markings. Color coding

requirements shall be included in textual form. Color graphics shall not be used to illustrate color coding

requirements. Item and container markings shall be included as applicable.

I.3.5.1.4 Coniguration Table. A coniguration table shall be included in landscape format. As a minimum,

the table shall list coniguration(s)/components by nomenclature and part number. The acquiring activity will

provide additional column headings as required (see I.6.2).

I.3.5.2 Safety Summary and Accident Prevention WP (WP 020 00). In addition to the safety summary

requirements of MIL-STD-38784, this WP shall contain information pertaining to accident prevention and shall

also contain a description of the following hazards: explosive; pneumatic; electrical (high voltage); chemical;

static electricity; environmental; other associated hazards. The following paragraph shall be included:
